Transition injection moulded fittings for water supply and gas transport pipelines
Technical Properties
| • Raw material | PE100 |
| • Max design T | 40 °C |
| • Max operating P | 25 bar @ 20°C |
| • Certifications | RINA – DVGW etc |
Transition fittings are essential to ensure the transition between metal pipes and high density polyethylene pipes.
The product range includes injection moulded adapters with plastic spigot for butt welding and, above all, a wide range of electrofusion transition fittings with threaded brass insert (male, female and female with free nut).
Steel/PE coupling
Range SDR11 PN16
| • A – galvanized | 25 ÷ 315 mm |
| • F – galvanized threaded | 25 ÷ 125 mm |
| • H – galvanized coated threaded | 25 ÷ 125 mm |
| D x D1 [mm x “] |
TYPE A |
TYPE F |
TYPE H |
|---|---|---|---|
| 25 x ¾” | *********** | *********** | *********** |
| 32 x 1″ | *********** | *********** | *********** |
| 40 x 1″ ¼ | *********** | *********** | *********** |
| 50 x 1″ ½ | *********** | *********** | *********** |
| 63 x 2″ | *********** | *********** | *********** |
| 75 x 2″ ½ | *********** | *********** | *********** |
| 90 x 3″ | *********** | *********** | *********** |
| 110 x 4″ | *********** | *********** | *********** |
| 125 x 4″ | *********** | *********** | *********** |
| 140 x 5″ | *********** | ||
| 160 x 6″ | *********** | ||
| 180 x 6″ | *********** | ||
| 200 x 8″ | *********** | ||
| 225 x 8″ | *********** | ||
| 250 x 10″ | *********** | ||
| 280 x 10″ | *********** | ||
| 315 x 10″ | *********** | ||
| 315 x 12″ | *********** |
Other dimensions upon request
Steel/PE bent coupling
Range SDR11 PN16
| • A – galvanized | 25 ÷ 63 mm |
| • R – galvanized coated | 25 ÷ 63 mm |
| D [mm] |
D1 [“] |
TYPE A |
TYPE R |
|---|---|---|---|
| 25 | ¾ | *********** | *********** |
| 32 | 1 | *********** | *********** |
| 40 | 1 ¼ | *********** | *********** |
| 50 | 1 ½ | *********** | *********** |
| 63 | 2 | *********** | *********** |
Other dimensions upon request
Copper/PE coupling
Range SDR11 PN16
| • PE diameter | 25 ÷ 32 mm |
| • Copper diameter | 18 ÷ 22 mm |
| D [mm] |
D1 [mm] |
SDR11 PN16 |
|
|---|---|---|---|
| 25 | 18 | *********** | |
| 25 | 22 | *********** | |
| 32 | 18 | *********** | |
| 32 | 22 | *********** |
Other dimensions upon request
Transition Brass Insert
Range SDR7.4 PN25
| • M – male threaded | 20 ÷ 110 mm |
| • F – female threaded | 20 ÷ 110 mm |
| • Insert metal | brass |
| D [mm] |
D1 [“] |
TYPE M |
TYPE F |
|---|---|---|---|
| 20 | ½ | *********** | *********** |
| 25 | ¾ | *********** | *********** |
| 32 | 1 | *********** | *********** |
| 40 | 1 ¼ | *********** | *********** |
| 50 | 1 ½ | *********** | *********** |
| 63 | 2 | *********** | *********** |
| 75 | 2 ½ | *********** | *********** |
| 90 | 3 | *********** | *********** |
| 110 | 4 | *********** | *********** |
* Free nut version available
Other dimensions upon request
EF Socket
Range SDR7.4 PN25
| • M – male threaded | 20 ÷ 110 mm |
| • F – female threaded | 20 ÷ 110 mm |
| • Insert metal | brass |
| D [mm] |
D1 [“] |
TYPE M |
TYPE F |
|---|---|---|---|
| 20 | ½ | *********** | *********** |
| 25 | ¾ | *********** | *********** |
| 32 | 1 | *********** | *********** |
| 40 | 1 ¼ | *********** | *********** |
| 50 | 1 ½ | *********** | *********** |
| 63 | 2 | *********** | *********** |
| 75 | 2 ½ | *********** | *********** |
| 90 | 3 | *********** | *********** |
| 110 | 4 | *********** | *********** |
* Free nut version available
Other dimensions upon request
EF Elbow 90°
Range SDR7.4 PN25
| • M – male threaded | 20 ÷ 110 mm |
| • F – female threaded | 20 ÷ 110 mm |
| • Insert metal | brass |
| D [mm] |
D1 [“] |
TYPE M |
TYPE F |
|---|---|---|---|
| 20 | ½ | *********** | *********** |
| 25 | ¾ | *********** | *********** |
| 32 | 1 | *********** | *********** |
| 40 | 1 ¼ | *********** | *********** |
| 50 | 1 ½ | *********** | *********** |
| 63 | 2 | *********** | *********** |
| 75 | 2 ½ | *********** | *********** |
| 90 | 3 | *********** | *********** |
| 110 | 4 | *********** | *********** |
* Free nut version available
Other dimensions upon request
EF Elbow 45°
Range SDR7.4 PN25
| • M – male threaded | 20 ÷ 110 mm |
| • F – female threaded | 20 ÷ 110 mm |
| • Insert metal | brass |
| D [mm] |
D1 [“] |
TYPE M |
TYPE F |
|---|---|---|---|
| 20 | ½ | *********** | *********** |
| 25 | ¾ | *********** | *********** |
| 32 | 1 | *********** | *********** |
| 40 | 1 ¼ | *********** | *********** |
| 50 | 1 ½ | *********** | *********** |
| 63 | 2 | *********** | *********** |
| 75 | 2 ½ | *********** | *********** |
| 90 | 3 | *********** | *********** |
| 110 | 4 | *********** | *********** |
* Free nut version available
Other dimensions upon request
EF Spigot Saddle
Range SDR11 PN16
| • M – male threaded | / |
| • F – female threaded | 110 ÷ 160 mm |
| • Insert metal | brass |
| D [mm] |
D1 [“] |
TYPE M |
TYPE F |
|---|---|---|---|
| 110 | 1 ½ | *********** | |
| 110 | 2 | *********** | |
| 125 | 1 ½ | *********** | |
| 125 | 2 | *********** | |
| 140 | 1 ½ | *********** | |
| 140 | 2 | *********** | |
| 160 | 1 ½ | *********** | |
| 160 | 2 | *********** |
Other dimensions upon request
| EN 12201-3 |
Plastics piping systems for water supply, and for drainage and sewerage under pressure – Polyethylene (PE) – Part 3: Fittings |
| EN 1555-3 |
Plastics piping systems for the supply of gaseous fuels – Polyethylene (PE) – Part 3: Fittings |
| EN ISO 15494 |
Plastics piping systems for industrial applications – Polybutene (PB), polyethylene (PE), polyethylene of raised temperature resistance (PE-RT), crosslinked polyethylene (PE-X), polypropylene (PP) – Metric series for specifications for components and the system |
